Grade 80 Eye Choke Hook ECK Type
Grade 80 Eye Choke Hook ECK Type Grade 80 Eye Choke Hook ECK Type Grade 80 Eye Choke Hook ECK Type Grade 80 Eye Choke Hook ECK Type Grade 80 Eye Choke Hook ECK Type Grade 80 Eye Choke Hook ECK Type
  • Grade 80 Eye Choke Hook ECK Type
  • Grade 80 Eye Choke Hook ECK Type

Grade 80 Eye Choke Hook ECK Type

Item No.: 502024
Grade 80 eye choke hook is used for loop lifting in choker slings. G80 alloy twist eye choke hook is designed for reeving applications with special hook and twist eye to connect ropes and paired with omega link in use.
Request Quote
Description
Description

H-Lift Grade 80 Eye Choke Hook, ECK Type features:

  • Grade 80 eye choke hook is used for loop lifting in choker slings. G80 alloy twist eye choke hook is designed for reeving applications with special hook and twist eye to connect ropes and paired with omega link in use.
  • Used with OML type omega link to form choker with chain.
  • Quenched & tempered.
  • 100% Magnaflux Crack Detection.
  • Standard: EN 1677
  • Material: Forged alloy steel
  • Proof load: 2.5 times the Working Load Limit
  • Safety factor: 4:1
  • Surface finish: Powder coated

 G-80 Eye Choke Hook

Item No. Chain Size WLL Main Dimensions(mm) Weight Product Code
mm ton A B C Φ Φ1 Φ2 Φ3 L kg
8-ECK-08 7+8 2 19 28 16.5 17 52 30.5 7.5 123 0.36 502024008
8-ECK-10 10 3.2 26 40 17.5 20 68 39 8 157 0.72 502024010
8-ECK-13 13 5.4 34 43 21 25 87 53 10 196.5 1.4 502024013
8-ECK-16 16 8.2 51 45.5 31 30 108 64 10.5 246 3.17 502024016
8-ECK-18 18 10 49.5 53 33.5 33.5 121 75 12 268.6 3.8 502024018
8-ECK-20 20 12.6 70 80 44 52 146 84 14 367 8.95 502024020
8-ECK-26 26 21.2 80 80 44 60 180 100 24.3 417 16.65 502024026
